About R&M's Manual Chain Hoists

Our RMII manual chain hoists are available as standard with a 10-foot lift, or with any custom lift height up to 98 feet. The standard top hook design can be paired with one of R&M's manual trolley options, or opt for an integral hand geared chain trolley or manual push trolley (1/2 - 5 ton [500 - 5000 kg] capacities), which lowers the overall headroom of the hand chain hoist and trolley.

Durability

• High strength, grade 80 alloy steel load chain with galvanized finish for corrosion resistance
• Hooks are alloy steel, heat treated and equipped with hook latches and inspection points
• Treated steel shafts, gears and load wheels
• Meets or exceeds international standards, including ASME B30.16

Safety

• Overload limiting device to prevent lifting loads beyond rated capacity (Except 1/4 ton [250 kg] unit)
• Dual pawl Weston-style brake with two brake friction discs provides four braking surfaces
• Load chain guard that holds chain to pockets of load wheel for safe operation
• Hooks are treated alloy steel and equipped with spring-return safety latches.
