Crane Operation Made Easy and Safe

The RaCon^® 3 remote control is designed to be used in conjunction with the Spacemaster^® SX wire rope hoists and the QX^® or QL crane packages. The ergonomic design allows operators a more comfortable grip to better control the load. With their full concentration on the load, crane operators can control the crane from the safest location with no restriction of a fixed-length pushbutton controller cable.

About the RaCon 3 Radio Controller

The RaCon 3 radio controller features a joystick for easy 2-axis control of the trolley and bridge motions. The hoisting buttons feature two-step momentary pushbuttons to safely control the hoisting speeds. The multi-function key switch allows for additional control or feature options, as designed for the equipment.

Standard Features

• Two-step momentary buttons for hoisting motion
• Joystick controls for trolley and bridge motions
• Emergency stop pushbutton
• Robust plastic housing with protection class IP65 rating
• Lightweight body and comfortable carrying hand strap
• LED indication of battery or operating status
• Operating time 16 hours at 50% effective duty
• Rechargeable Li-ion batteries
• Indoor or outdoor operation
• Internal antenna protected inside the receiver and in the transmitter

Racon transmitter models ending with MI, EC and SP have a vibration alarm as standard. When the battery is running low, the alarm goes off and the transimitter starts vibrating. Vibration alarms are optional in some models.
